HIKVISION NVR DS-7700NI-I4 – 32 Channels

Untitled-2

HIKVISION NVR DS-7700NI-I4 – 32 Channels

HIKVISION NVR DS-7700NI-I4 – 32 Channels

HIKVISION DS-7700NI-I4 NVR DS-7700NI-I4 – 32 Channels

DS-7700NI-I4, HIKVISION NETWORK VIDEO RECORDER (NVR) 32 Channels.

SKU: DS-7700NI-I4 Categories: NVR & Controllers, SURVEILLANCE & COUNTERS Brand: Hikvision

Description
Additional information

HIKVISION NETWORK VIDEO RECORDER (NVR)

Hikvision DS-7700 Series DS-7700NI-I4 Embedded 4K – 32 channels, features optimized H.265+ and H.264+ compression codecs, enabling highly effective bandwidth and storage management. With plug-and-play functionality,

Features:

Third-party network cameras supported
Up to 12 Megapixels resolution recording
Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K(3840×2160) resolution
6/32-ch network cameras can be connected with 160M/256M incoming bandwidth
Up to 4 SATA interfaces
Support dual-os to ensure high reliability of the system running
Support various VCA detection alarm and VCA search
Support H.265/H.264/MPEG4 video formats

Downloads:

Weight	5 kg
Dimensions	40 × 44.5 × 7.1 cm
General	Connectable to the network cameras. Each channel supports dual-stream. Up to 8 network cameras can be added. Independent configuration for each channel, including resolution, frame rate, bit rate, image quality, etc. The quality of the imported and exported record is configurable.
HDD Management	 Up to 2 SATA hard disks, 8 network disks (8 NAS disks, or 7 NAS disks+1 iSCSI disk) can be connected, each disk with a maximum of 4TB storage capacity.  Support S.M.A.R.T. and bad sector detection.  HDD group management.  Support HD D standby function.  HDD property: redundancy, read – only, read/write (R/W).  HDD quota management; different capacity can be assigned to different channel.
Recording and Playback	 Holiday recording schedule configuration.  Cycle and non – cycle recording mode.  Normal and event video encoding parameters.  Multiple recording types: manual, continuous, alarm, motion, motion, alarm, motion & alarm.  8 recording time periods with separated recording types.  Pre – record and post – record for alarm, motion detection for rec ording, and pre – record time for schedule and manual recording.  Searching record files by events (alarm input/motion detection).  Customization of tags, searching and playing back by tags.  Locking and unlocking record files.  Local redundant recording.  Search ing and playing back record files by channel number, recording type, start time, end time, etc.  Zooming in for any area when playback.  Playing reversely.  Adverse Playback for Multi – channel.  Supports pause, play reversely, speed up, speed down, skip forward , and skip backward when playback, locating by dragging the mouse.  Up to 8 – ch synchronous playback at 4CIF real time.
Backup	Support NTFS and FAT32 formatted backup devices. Export data by USB devices. Export video clips when playback. Management and maintenance of backup devices.
Alarm and Exception	 Configurable arming time of alarm input/output.  Alarm for video loss, motion detection, tampering, abnormal signal, different input and output video standard, illegal login, network disconnected, IP conflicti on, record exception , HDD error, and HDD full, etc.  Alarm triggers full screen monitoring, audio alarm, notifying surveillance center, sending email and alarm output.  Automatic restore when system is abnormal.
Other Local Functions	 Control via mouse, remo te control and special keyboard.  Three – level user management; admin user can create many operating account and define their limits of authority, which includes the limit to access any channel.  Completeness of operation, alarm, exceptions and log writing an d searching.  Import/export of device configuration files.
Network Functions	 1 self – adaptive 10M/100M/1000M network interface.  4 independent PoE network interfaces are provided.  IPv6 is supported.  TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, S NMP, NFS, UPnP, and iSCSI are supported.  TCP, UDP and RTP for unicast.  Remote search, playback, download, locking and unlocking the record files, and downloading files broken transfer resume.  Remote parameters setup; remote import/export of device paramete rs.  Remote viewing of the device status, system logs and alarm status.  Remote keyboard operation.  Remote HDD formatting and program upgrading.  Remote system restart and shutdown.  RS – 485 transparent channel transmission.  Alarm and exception information can be sent to the remote host .  Remotely start/stop recording.  Remotely start/stop alarm output.  Remote PTZ control.  Embedded WEB server.
Development Scalability	SDK for Windows and Linux system. Source code of application software for demo. Development support and training for application system.
